Product Description

Limited Time Free Shipping

This Oregon 28-ton log splitter with the commercial Honda 270 CC engine (model 596280) allows splitting logs up to 24″ in length.

Included with this log splitter is the EXtendSplit work zone making is easier to maneuver and split wood. The wood splitter is also fully road towable with 2″ coupler and safety chains.

*Engine shown is a Kohler; however, this listing comes with a Honda Motor.

More info: Manual

Please note about residential / lift gate delivery:

You must select the $75 lift gate option if this shipment is going to a residence (unless you can unload the 700+ pound crate with something like a fork lift).

These deliveries are “curb-side” only, please read the details about curb-side, lift gate and residential freight deliveries.

Questions? Feel free to contact us at 888-706-2434.

Detailed Specifications

Engine:
Honda Engine -GX270 (270CC)

Splitting Wedge:
8″ Cast Steel

Operating Position:
Horizontal / Vertical

Force / Tonnage:
28 Ton (56,000lbs)

Cylinder:
4.5″ x 24″

Cycle Time:
12-14 Seconds (Approx)

Log Opening:
25 Inches

Wheels & Tires:
High-Speed, 4.80 x 8

Road Towable:
Yes – 2″ Coupler & Safety Chains

Hydraulic Filter:
Yes – Included

Operating Size:
92″ x 49″ x 43

Hydraulic System:
Up to 8 Gallons

Safety Control Valve:
Detent – Auto Return

2 Stage Pump:
Yes – 16 Gallons Per Minute

Log Cradle:
Yes – built in

Log Catcher:
No

Crate Dimensions:
72″L x 36″W x 24″H

Consumer Warranty:
Yes – 3 Year Limited

Shipping Weight:
650 LBS

4 Way Wedge:
No

Working Height:
31.5 Inches

Log Dislodgers:
Yes – Included

Assembly Required:
Yes – Partially Assembled
